Electric Recovery Winch, 2,000 to 20,000 lb, 12 or 24 V, Wire Rope or Dyneema

A winch is only useful if it pulls when the vehicle cannot. This range covers 2,000 lb to 20,000 lb of rated pull, in two line options: galvanised steel wire rope for abrasion resistance, and Dyneema synthetic rope for handling and weight. The smaller sizes run from 12 V or 24 V vehicle power and are the ones fitted to 4x4s, trailers and recovery trucks.

Electric Recovery Winches: Overview

Rated pull runs from 2,000 lb, which handles a light trailer or a quad, up to 12,000 lb for a full-size 4×4 and 20,000 lb for truck and plant recovery. The rating is the first layer of rope on the drum; pull falls as the rope builds up, which is why most recovery guidance suggests a winch rated at around 1.5 times the vehicle weight.

Each capacity is offered with steel wire rope or Dyneema synthetic rope. Wire rope resists abrasion and heat and is the cheaper option; Dyneema is lighter, does not store energy the way a broken wire rope does, and is easier to handle with gloves, but it needs a protective sleeve where it runs over rock or a sharp edge.

Power is taken from the vehicle at 12 V or 24 V, so the winch runs from the battery and charging system rather than from a separate power pack. Battery condition and cable size matter more than the winch rating on a long pull.

Key Features at a Glance

• 2,000 to 20,000 lb – from trailer and quad work up to truck and plant recovery.
• Wire rope or Dyneema – each capacity is available in both line types.
• 12 V and 24 V – runs from the vehicle battery and charging system.
• Geared drum drive – the reduction set that gives the rated pull at a controlled line speed.
• Free-spool to pay out – the drum can be released so the line is pulled out by hand.
• Mounting plate pattern – bolts to a standard winch bumper or a fabricated plate.

Rating, Line and Power

Sizing the winch to the vehicle

Take the loaded weight of the vehicle, add the weight of anything it is dragging, and allow a margin. A 2,000 lb winch suits a light trailer or a quad; 3,500 lb to 4,500 lb covers a small 4×4; 9,500 lb to 12,000 lb is the usual fit for a full-size 4×4; 20,000 lb is truck and plant recovery.

The rated pull is measured on the first layer of rope on the drum. As the rope builds up, the effective pull drops, so a winch that is only just rated for the vehicle will be short of pull on the last layers.

Wire rope or Dyneema

Steel wire rope is abrasion resistant and tolerant of heat, and it is the lower-cost option. It stores energy when it breaks, so a damper or a heavy blanket over the line is standard practice on a hard pull.

Dyneema synthetic rope is lighter on the drum, does not whip dangerously when it parts, and is easier to handle. It cuts on sharp edges and degrades with heat, so it wants a sleeve or a fairlead and it should not be dragged over rock.

Fitting and Using

Wiring and battery load

Run cable sized for the full current of the winch, keep the run as short as practical, and land the earth on the chassis rather than on a body panel. A winch pulling hard draws a heavy current, and undersized cable turns into heat and lost pull.

Keep the engine running while winching so the alternator is contributing. On repeated pulls, let the motor and the solenoid cool between runs; the duty cycle, not the rating, is what limits how long a recovery winch can work.

Pulling safely

Lay the line out straight where possible, use a snatch block to double the pull or change direction, and keep everyone clear of the line and of the anchor. Never stand over a loaded rope.

Use a rated recovery point and a tree strap rather than a hook straight onto a chassis member. On a long pull, put a damper over the line and check the rope for kinks and flattened strands before the next use.

Available Models and Prices

All models are in stock. Prices are per unit in USD. Rope length varies by model; confirm the required length when ordering.

Specifications

Packaging Information

Heavy units ship crated or on a pallet by freight; the carriage cost is quoted per order before dispatch.

Where It Is Used

4×4 and off-road recovery, trailer and equipment loading, recovery trucks and breakdown vehicles, farm and forestry work, boat trailers, and workshop pulling and dragging where a hand winch is not enough.

Choosing the Right Unit

1. Size the unit on the heaviest realistic load plus a margin, not on the average load.
2. Measure the lift or the travel distance before choosing, and leave allowance for the drum or the chain bag.
3. Match the wheel or castor material to the surface the unit will run on.
4. Check the supply: three-phase for industrial hoists, single-phase where only a domestic supply is available.
5. For anything that has to be shipped, get a freight quote on the packed weight before setting the retail price.

Care and Maintenance

Check the rope or chain, the hook and the brake before each shift, and never exceed the stated capacity.

Load the heaviest part low and over the axle or the drum, and keep the load under control with a tag line on a long lift.

Keep the chain or rope lightly oiled, the drum and guide clean, and replace any worn or distorted part rather than dressing it.

Check the fixing point as well as the unit: a beam or bracket that holds the hoist still has to carry the load.

OEM and Bulk Supply

The supplier works to order with own-brand marking and packaging, and accepts OEM and ODM work.

Frequently Asked Questions

Which options are available?

This listing covers 18 options: 2,000 lb, wire rope; 3,000 lb, wire rope; 3,500 lb, wire rope; 4,000 lb, wire rope; 4,500 lb, wire rope; 6,000 lb, wire rope; 9,500 lb, wire rope; 12,000 lb, wire rope; 2,000 lb, Dyneema; 3,000 lb, Dyneema; 3,500 lb, Dyneema; 4,000 lb, Dyneema; 4,500 lb, Dyneema; 6,000 lb, Dyneema; 9,500 lb, Dyneema; 12,000 lb, Dyneema; 20,000 lb, wire rope; 20,000 lb, Dyneema. All are in stock and priced individually.

What is it used for?

4×4 and off-road recovery, trailer and equipment loading, recovery trucks and breakdown vehicles, farm and forestry work, boat trailers, and workshop pulling and dragging where a hand winch is not enough.

Can I buy in bulk or with my own branding?

Yes. Own-brand marking and packaging are available on request, with OEM and ODM support.

Summary

A winch is only useful if it pulls when the vehicle cannot. Offered in 18 configurations, each priced separately.

Typical use:

4×4 and off-road recovery, trailer and equipment loading, recovery trucks and breakdown vehicles, farm and forestry work, boat trailers, and workshop pulling and dragging where a hand winch is not enough.
