Of Bosch model 26 light hammer electric pick, household hand drill, multi-purpose impact drill
$37.30
SDS Plus rotary hammer with hammer, drill and chisel functions for concrete, brick and block, supplied as a bare unit or a kit.
Shipping & Delivery
-
Standard courier delivery
Tracked door-to-door delivery from our Shenzhen warehouse.
6-25 business days, depending on destination
From $7.30 · Free shipping from $99 (by order weight)
-
Express courier delivery
DHL, FedEx or UPS will deliver to the specified address.
2-8 business days, depending on destination
From $13.90
-
12-month warranty
-
30-day returns
Frequently Bought Together
More in This Category
Corded Impact Drill with Speed Switch, Brushed Motor, Stone and Wood Drilling
Price range: $11.99 through $35.99
Brushless Cordless Impact Drill, Keyed Chuck, Renovation, Engineering, Repair, With Bit
Price range: $59.99 through $130.99
Cordless Drill Driver Kit, DC 48-110 V, Keyed Chuck, Household Drilling & Home Improvement
Price range: $39.99 through $72.99
Cordless Drill and Screwdriver, Eight Kit Options, Makita-Style Battery
Price range: $24.15 through $44.63
Brushless Cordless Drill with Rear Handle, Multi-Speed, Seven Kits
Price range: $13.70 through $39.68
Brushless Cordless Drill, 21 V, 30 Nm, 1.5 Ah, Standard or Impact, Kit Options
Price range: $24.72 through $61.26
H.ROCYK cross-border best-selling stepless speed regulation mini electric grinding jade carving machine
Price range: $11.76 through $30.62
Self-Adhesive Backing Pad, 360 Degree Swivel Head, for Wall and Ceiling Sanding
Price range: $8.99 through $19.67
Mini Rotary Tool, Cordless, Variable Speed, for Carving and Polishing
Price range: $11.19 through $16.16
Product Information
Product Attributes
| Concrete drilling and light demolition |
Packaging Information
Unit weight and carton dimensions for every model in this listing.
| Model | Weight (lb) |
|---|---|
| Unit | 6.614 |
Figures are measured per single unit. Carton quantities and mixed pallets are available on request.
A rotary hammer is a different tool from an impact drill: the piston does the work, so the user only guides the bit. That is what lets it drill concrete all day rather than a dozen holes. This unit is SDS Plus with a chisel function. Made by Chuangxin.
Rotary Hammer: Overview
The hammer mechanism drives a piston against the bit, so the drilling energy comes from the tool rather than from pressure applied by the operator. The result is faster drilling in hard material and far less effort.
SDS Plus tooling is held in a slotted shank that allows the bit to move axially as it hammers, which is why these drills use SDS bits rather than round shanks.
Three functions cover the jobs the tool is bought for: hammer drilling for fixings, drilling only for light work and chiselling for taking out tiles and chasing.
Key Features at a Glance
- SDS Plus chuck – takes the standard hammer bits and chisels.
- Three functions – hammer drill, drill only and chisel.
- Piston hammer mechanism – the tool does the work, not the user.
- Concrete, brick and block – for fixings and openings.
- Chisel function – tiles, render and light demolition.
- Bare unit or kit – buy what is needed.
Using a Rotary Hammer
Choosing the mode
Use hammer drilling for concrete and masonry, drill only for timber, steel and tiles, and the chisel function for tiles, render and chasing. Running the chisel mode against a wall that has to stay intact is how edges get broken out.
Let the bit cool between holes on long runs. The bit tip is the part that wears, and a hot tip loses its edge and stops cutting at the rate the tool is capable of.
Bits and dust
Match the bit to the fixing: the plug or anchor decides the hole size, and a hole drilled one size large holds nothing.
Clear the hole before the fixing goes in. Dust left in the hole is the usual reason a wall plug pulls out, and a blow-out pump or a blow and brush takes seconds.
Care
Grease and brushes
Check the grease in the SDS chuck and top it up on the supplier’s schedule. A dry chuck wears its slots and the bit starts to wobble, which is the beginning of the end for the tool.
Blow dust out of the vents and check the cord before use. Hammers work in dust, and dust is what kills the motor.
Storage
Store in the case with the bits in the holder, and keep it dry. Chisels and bits are stored with the cutting edge protected so they do not chip against each other.
Available Models and Prices
| Model | Option | Price (USD) |
|---|---|---|
| Rotary Hammer | $37.30 |
All options are in stock. Prices are per unit in USD; carton prices on request.
Specifications
| Type | SDS Plus rotary hammer |
| Functions | Hammer drill, drill only and chisel |
| Chuck | SDS Plus |
| Power | Corded, 220 V |
| Applications | Concrete, brick and block drilling and light demolition |
| Packed weight (base unit) | 6.614 lb (3 kg) |
| Country/region of origin | China |
| Model options | 1 configuration available |
Packaging Information
| Model | Weight (lb) |
|---|---|
| Unit | 6.614 |
Hammers ship in a case or boxed; carton quantities are available on request.
Where It Is Used
Fixing into concrete, brick and block, drilling for wall plugs and anchors, taking out tiles and render, chasing, and light demolition work on site and in renovation.
Choosing a Rotary Hammer
- Size by the largest bit the job needs: the tool is bought for the fixing, not for the spec sheet.
- Three functions cover drilling and light demolition; a two-function tool is enough for drilling only.
- SDS Plus for general site work; SDS Max for heavy breaking.
- Check that bits and chisels are available in the shank the tool takes.
Care and Maintenance
Check and top up the chuck grease on schedule.
Blow dust out of the vents and check the cord before use.
Clear drilled holes before fitting plugs or anchors.
Store in the case with the bit edges protected.
OEM and Bulk Supply
Own-brand printing, custom kit contents and retail packaging are available on request, with OEM and ODM support.
Frequently Asked Questions
Is this a single item or a set?
It is supplied as described above – SDS Plus rotary hammer. One unit per order.
What is it used for?
Fixing into concrete, brick and block, drilling for wall plugs and anchors, taking out tiles and render, chasing, and light demolition work on site and in renovation.
Can I buy in bulk or with my own branding?
Yes. Own-brand printing, packing and kit building are available on request, with OEM and ODM support.
Summary
A rotary hammer is a different tool from an impact drill: the piston does the work, so the user only guides the bit.
Typical use: Fixing into concrete, brick and block, drilling for wall plugs and anchors, taking out tiles and render, chasing, and light demolition work on site and in renovation.
